Main technical specifications indicators:
Standard: ISO-F flange
Body material:304L & Disc material:304L Surface treating: EP（Electrolytic polishing） N.W: 49.3 kg
1.operate pressue range：1.1×10 -8 mabr to 1.6 bar
2.mounting position: Brake-level or vertical
3.leak rate:< 5×10 -9 mbar · l/s & 1×10 -8 mbar · l/s
4.cycle life：≧ 200,000times
5. differential pressure on the gate: ≤ 30 mbar & ≤ 1.
6 bar 6.Bake-out temperature:≤ 200℃(Stainless steel)
7.Temperature for valve body：≤ 200℃
8.Temperature for actuator：≤ 100℃
9.Compressed air:4 to 7 bar ( 0.5～0.7MPa)
10. Gate seal + Bonnet seal: Viton FKM or [FFKMViton] (Choice)
11.Valve body material: SS304L (Optional for SS316L )
12.Mechanism material: SS304L (Optional for SS316L )
13.Actuator material: SS304L (Optional for SS316L or Aluminum )
14.Failure protection : Mechanism lock system
15.Valve: Low dust/low vibration
■ Patented mechanism
■ Low maintenance cost
■ Low particle generation
■ Low shock
■ Valve locked in close position
